Hydraulic Mobile Scissor Lift Elevated Work Platform 220V 380V 450V Optional

Scissor Working Electric Hydraulic Mobile Elevated Platform

Another key difference between Hydraulic Construction Scissor Lifts and traditional scaffolding is that lifts are powered by hydraulic or electric means. This means that they can be easily adjusted to different platform heights, making them suitable for a wide range of tasks.

In summary, Hydraulic Construction Scissor Lifts are a versatile and efficient tool for accessing elevated work areas in various fields. They offer several advantages over traditional scaffolding, including faster setup, greater mobility, and improved safety features.

Basic Parameter:

Model No.	Table Size	Loading Capacity	Platform Height	Working Height (m)	Retract Height (m)	Voltage	Overall size	N.W.(kg)
MSL0504	2100*830	500	4	6	1.2	1 or 3phase	22509501100	800
MSL0506	2100*830	500	6	8	1.2	1 or 3phase	22509501200	880
MST0507	2100*830	500	6.8	8.8	1.28	1 or 3phase	22509501200	970
MST0508	2100*930	500	8	10	1.38	1 or 3phase	225010601380	1050
MST0509	2100*930	500	9	11	1.5	1 or 3phase	225010601500	1165
MST0510	2100*1230	500	10	12	1.53	1 or 3phase	225013501530	1360
MST0311	2100*1230	300	11	13	1.65	1 or 3phase	225013501650	1400
MST0512	2550*1530	500	12	14	1.75	1 or 3phase	279616701750	2260
MST0514	2812*1530	500	14	16	1.81	1 or 3phase	306717301810	2486
MST0316	2812*1600	300	16	18	2.08	1 or 3phase	306718102080	3063
MST0318	3070*1600	300	18	20	2.08	1 or 3phase	332118102080	3900
MST1004	2100*1200	1000	4	6	1.18	3phase	225013501180	1250
MST1006	2100*1200	1000	6	8	1.3	3phase	225013501300	1400
MST1008	2100*1200	1000	8	10	1.42	3phase	225013501420	1585
MST1010	2100*1200	1000	10	12	1.53	3phase	225013501530	1700
MST1012	2550*1530	1000	12	14	1.75	3phase	279617001780	2560
MST1014	2812*1600	1000	14	16	1.81	3phase	306718101900	3230
MST1506	2100*1530	1500	6	8	1.53	3phase	225017501530	1780
MST1508	2100*1530	1500	8	10	1.69	3phase	225017501690	2070
MST1510	2100*1500	1500	10	12	1.85	3phase	225017501850	2250
MST1512	2600*1500	1500	12	14	1.85	3phase	300019002300	3500
MST1514	3200*1600	1500	14	16	1.96	3phase	350020002200	5000
MST2006	2100*1530	2000	6	8	1.53	3phase	225017501530	1780
MST2008	2100*1530	2000	8	10	1.69	3phase	225017501690	2070
MST2010	2100*1530	2000	10	12	1.85	3phase	225017501850	2250
MST2012	2600*1500	2000	12	14	1.954	3phase	300019002300	4500
MST2014	3200*1600	2000	14	16	2.23	3phase	350020002500	5500

Hydraulic Mobile Scissor Lift Elevated Work Platform 220V 380V 450V Optional

The unique configurations of the mobile scissor lift include:

A platform made of sturdy 60mm x 40mm rectangular tubing and reinforced with a 3mm checkered iron plate.
Scissors constructed of high strength manganese steel measuring 150mm x 50mm x 5mm.
A hydraulic system powered by a 310 10ml/r pump.
High precision hydraulic cylinders, with two sets of ￠80 and two sets of ￠100.
Durable piston rods, featuring ￠40 and ￠50 with a hard chromium plating surface.
A high-pressure oil pump and hydraulic oil adjusted for summer at 45＃ and winter at 32＃.
600-9 rubber wheels, with four pieces in total.

In terms of safety, the mobile scissor lift is equipped with:

Explosion-proof valves for added protection.
Anti-skid plate for secure footing.
Overload protective system to prevent overloading.
Single control solenoid valves to prevent dropping in the event of power failure.
Emergency decline valve for emergency situations.
Four supporting legs for added stability.

Our Electric Scissor Man Lift incorporates industry-leading technology to deliver exceptional performance and functionality. From advanced control systems to precision hydraulic components, every aspect of the lift is engineered with cutting-edge technology. This ensures smooth and precise operation, precise positioning, and enhanced safety features, allowing operators to work with confidence and efficiency.

Safety is paramount in the design of our Electric Scissor Man Lift. It is equipped with intelligent safety features that provide a secure working environment for operators. These features include anti-collision sensors, automatic leveling, emergency lowering, and overload protection. By prioritizing safety, we ensure that your operators can focus on their tasks without compromising their well-being.
